The Cisco C9200L-48T-4X-E is a Catalyst 9200L access switch with 48 10/100/1000 data ports and four 1/10G SFP+ fixed uplinks. It is the Network Essentials version, which covers foundational Layer 2 and Layer 3 switching, automation, visibility, and security. Cisco DNA subscriptions are sold separately.
Cisco rates it at 176 Gbps switching capacity and 130.95 Mpps forwarding rate, or 256 Gbps and 190 Mpps in a stack. It has two power supply slots and uses the PWR-C5-125WAC as its default supply; a second identical supply adds redundancy. Two fixed fans handle cooling. Up to eight C9200L switches with the same license level stack over StackWise-80 at 80 Gbps, and the switch holds 16,000 MAC addresses.
This unit ships with an AC power cord, one PWR-C5-125WAC power supply, and a set of rack-mount brackets.
For the Network Advantage feature set, see the Cisco C9200L-48T-4X-A. If 1G uplinks are enough, the Cisco C9200L-48T-4G-E is the matching model. To stack it, add a C9200L-STACK-KIT. A second PWR-C5-125WAC power supply adds power redundancy.
This seller refurbished Cisco C9200L-48T-4X-E switch is tested, working, and covered by the NetworkTigers one-year warranty.
- Network Ports : 48x 1 Gigabit Ethernet RJ45
- Uplink Ports : 4x 10GB SFP+
- Management Ports : 1x RJ45 Console, 1x Gigabit Management, 2x USB, 1x Mini USB
- Stacking Ports : StackWise 80 possible through the use of C9200L-STACK-KIT - ordered separately.
- Stacking Options : StackWise 80 provides 80 Gbps of stacking bandwidth support - Up to 8 Members in a stack - Only other C9200L models with same license level can be stacked together
- Stacking Cable Options : STACK-T4-50CM, STACK-T4-1M, STACK-T4-3M
- Switch Version : Network Essentials
- Fan Module Options : 2x fixed fans, built in (not field-replaceable)
- Power Supplies Included : 1x PWR-C5-125WAC (2 power supply bays)
- Power Supply Options : PWR-C5-125WAC, PWR-C5-600WAC, PWR-C5-1KWAC, PWR-C5-715WDC
- Switching Capacity : 176 Gbps
- Forwarding Rate : 130.95 Mpps
- MAC Address Table Size : 16,000
- VLAN ID's : 4096
- DRAM and Flash : 2 GB DRAM, 4GB Flash
- Model Number : C9200L-48T-4X-E
- Part Number : C9200L-48T-4X-E, C9200L-48T-4X-E=, C9200L-48T-4X-E-WS
- Condition : Seller refurbished
- One (1) Seller Refurbished Cisco C9200L-48T-4X-E Catalyst 9200L Series 48x 1GB RJ45 4x 10GB SFP+ Switch as described above
- One (1) Power Cord Included
- One (1) AC Power Supply Included
- One (1) Set of Rack Mount Brackets Included
- Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website - Transceiver Modules Not Included
