Supplied NEW in open box, the Cisco Catalyst C9300-24P-E (Network Essentials version) is a 24-port Gigabit PoE+ access switch for office, school, and retail sites that starts as a single closet switch and stacks to eight units.
- Eight switches, one stack: Link up to eight Catalyst 9300 switches of the same version over 480 Gbps stack cables for up to 192 PoE+ ports under one management point. Catalyst 9300X models can join; fixed-uplink 9300L and Catalyst 3850/3650 switches cannot.
- Power that scales with the stack: 445W of PoE is available from the default 715W supply, and an 1100W supply or a second 715W supply lifts it to the 720W needed for 30W on all 24 ports. StackPower pools supplies across up to four switches, or eight with the XPS-2200.
- Match the uplink to your core: Choose a C9300-NM-4G (4x 1G), C9300-NM-4M (4x Multigigabit), C9300-NM-8X (8x 10G/1G), C9300-NM-2Y (2x 25G/10G/1G), or C9300-NM-2Q (2x 40G) module.
- Serviced without replacing the switch: Power supplies and the three N+1 fans (FAN-T2) are field-replaceable, and the switch carries 8 GB of memory and 16 GB of flash storage.
Compare: Need more ports? The NEW C9300-48P-E offers 48 PoE+ ports. Don't need PoE? The C9300-24T-E is data-only.
It ships as the switch itself. See all Cisco Catalyst 9300 switches and parts.
This Cisco C9300-24P-E switch is new open box and covered by the NetworkTigers one-year warranty.
- Network Ports : 24x 1 Gigabit Ethernet PoE+ RJ45
- Product Family : Catalyst 9300 Series
- Management Ports : 1x RJ45 Console, 1x USB Mini-B Console, 1x 10/100/1000 RJ45 Ethernet Management, 1x USB Type A (storage), 1x USB 3.0 SSD Slot
- Stacking Ports : 2x StackWise 480 Ports (480 Gbps Stacking Bandwidth), 2x StackPower Ports
- Stack Members : Up to eight switches can be connected in the stack | Supported stack members = Other C9300 SKUs with same license level - C9300 higher scale SKUs only stack with other like higher scale models
- Stacking Cable Options : STACK-T1-50CM, STACK-T1-1M, STACK-T1-3M, CAB-SPWR-30CM, CAB-SPWR-150CM - Cables sold separately
- Module Slots : 1x Expansion Module Slot - Modules are not included
- Module Options : C9300-NM-4G, C9300-NM-8X, C9300-NM-2Q, C9300-NM-4M, C9300-NM-2Y - Please note - Existing 3850 network modules are also supported in the Cisco Catalyst 9300 Series platforms.
- Switch Version : Network Essentials
- Fan Module Options : 3x FAN-T2 (3 fan bays)
- Power Supplies Included : 1x PWR-C1-715WAC (2 power supply bays)
- Power Supply Options : PWR-C1-350WAC, PWR-C1-715WAC, PWR-C1-1100WAC, PWR-C1-715WDC, PWR-C1-350WAC-P, PWR-C1-715WAC-P, PWR-C1-1100WAC-P, PWR-C1-1900WAC-P
- PoE Budget : 445W (720W with 2nd PSU)
- Switching Capacity : 208 Gbps (688 Gbps with Stacking)
- Forwarding Rate : 154.76 Mpps (511.90 Mpps with Stacking)
- MAC Address Table Size : 32000
- Model Number : C9300-24P-E
- Part Number : C9300-24P-E, C9300-24P-E=, C9300-24P-E-WS
- Condition : New
- One (1) NEW Cisco C9300-24P-E Catalyst 9300 24x 1GB PoE+ RJ45 1x Module Slot Switch as described above
