A NEW Cisco Catalyst C9300L-48P-4G-E (Network Essentials version), supplied in open box, gives wiring closets 48 Gigabit PoE+ ports with four fixed 1G uplinks, and it stacks with up to seven others through the optional kit.
- Uplink speed by model: Uplinks are fixed, so speed is chosen with the model: four 1G SFP here, four 10G/1G SFP+ on the -4X, or two 40G QSFP+ on the C9300L-48UXG-2Q.
- Stack cables up to 3m: The optional stack kit has two adapters and a 0.5m cable, with 1m and 3m cables also offered for stacks of up to eight.
- RAM, flash, and USB slot: Each switch has 8 GB of memory and 16 GB of flash, plus a USB 3.0 slot that takes an SSD up to 240 GB.
- Power draw at 115V: With no PoE load, Cisco's published measurements show 68.42W with no link and 90.01W at full-port traffic.
Compare: Need more PoE? The NEW C9300L-48PF-4G-E provides 890W by default. Want fewer ports? The NEW C9300L-24P-4G-E has 24 PoE+ ports.
What ships with this unit is listed under What's Included. See all Cisco Catalyst 9300 switches and parts.
This unit is NEW in open box and sold with warranty. Need several, or a matched set with power supplies and fans? Ask us for a quote.
- Network Ports : 48x 1 Gigabit Ethernet PoE+ RJ45 - 802.3at (30W per port)
- Uplink Ports : 4x 1 Gigabit Ethernet SFP
- Management Ports : 2x USB, 1x Mini USB
- Stacking Ports : 2x StackWise-320 connectors (on the rear of switch) - Optional Stacking Hardware - C9300L-STACK-KIT - ordered separately
- Stacking Options : Only other C9300L SKUs with same license level. Number of stack members = 8. Stacking Bandwidth = 320 Gbps
- Stacking Cable Options : STACK-T3-50CM, STACK-T3-1M, STACK-T3-3M - None Included
- Switch Version : Network Essentials
- AirFlow Direction : Front-to-Back Airflow
- Fan Module Options : 3x FAN-T2 Fan Modules Included
- Power Supplies Included : 1x PWR-C1-715WAC-P Included - 2nd Power Supply ordered separately.
- Power Supply Options : Not Included - Options are PWR-C1-350WAC-P, PWR-C1-715WAC-P, PWR-C1-1100WAC-P
- PoE Budget : 505W (720W w/ 2nd PSU) - 2nd PSU allows PoE+ 802.3at (30W per port) for 24 ports - All 48 ports at PoE 802.3af (15.4W per port) with 2nd PSU.
- Switching Capacity : 104 Gbps (Switching Capacity with Stacking - 424 Gbps)
- Forwarding Rate : 77.38 Mpps (Forwarding Rate with Stacking - 315.48 Mpps)
- MAC Address Table Size : 32,000
- Model Number : C9300L-48P-4G-E
- Part Number : C9300L-48P-4G-E, C9300L-48P-4G-E=, C9300L-48P-4G-E-WS
- Condition : New
- One (1) NEW Cisco C9300L-48P-4G-E 48x 1GB PoE+ RJ45 4x 1GB SFP Switch as described above
