Cisco Catalyst C9500-16X-2QA, manufactured by Cisco, is a fixed core switch in a 1RU rack-mount form factor with 16 x 10 Gigabit SFP+ ports and 2 x 40 Gigabit QSFP+ uplinks via a network module.
It runs Cisco IOS XE with Network Advantage licensing and supports Layer 2 and Layer 3 features. The switch uses dual hot-swappable power supplies and front-to-back airflow. It fits campus core or aggregation roles where high port density of 10 GbE and 40 GbE uplinks are required.
Cisco C9500-16X-2Q-A: Catalyst 9500 16-port 10G switch, 2 x 40GE Network Module, NW Adv. License.
- Network Ports : 16x 1/10 Gigabit Ethernet SFP/SFP+
- Uplink Ports : 2x 40 Gigabit Ethernet QSFP+ (via NM-2Q module)
- Management Ports : 1x RJ-45, 1x USB Mini Type-B
- Stacking Ports : None Dedicated
- Stacking Options : Cisco StackWise Virtual
- Stacking Cable Options : Uses standard network cables (SVL)
- Module Slots : 1 - 1x C9500-NM-2Q Included
- Module Options : C9500-NM-8X (8x 1/10GE), C9500-NM-2Q (2x 40GE)
- Switch Version : Network Advantage
- AirFlow Direction : Front-to-Back
- Fan Module Options : 5x Fan Module Slots - 5x FAN-T4-R Included
- Power Supplies Included : 1x PWR-C4-950WAC-R (default)
- Power Supply Options : PWR-C4-950WAC-R (950W AC), PWR-C4-950WDC-R (950W DC)
- PoE Budget : N/A
- Switching Capacity : Up to 480 Gbps
- Forwarding Rate : Up to 360 Mpps
- MAC Address Table Size : Up to 64,000
- DRAM and Flash : 16 GB DRAM / 16 GB Flash
- Model Number : C9500-16X-2Q-A
- Part Number : C9500-16X-2Q-A
- Condition : Seller refurbished
- One (1) Seller refurbished Cisco C9500-16X-2Q-A 16x 10GB SFP+ 2x 40GB QSFP+ (via NM) NW Adv Switch as described above
- One (1) Power Cord Included
- One (1) AC Power Supply Included
- Five (5) Fan Modules Included
- One (1) Network Module Included
- One (1) Set of Rack Mount Brackets Included
- Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website - Transceiver Modules Not Included
