NEW Arista DCS-7148SX-F 7100 Series 48x 10GB SFP+ Front-to-Back Airflow Switch
New

NEW Arista DCS-7148SX-F 7100 Series 48x 10GB SFP+ Front-to-Back Airflow Switch

Ask for quote
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-2737

Overview

The DCS-7148SX-F is a 1RU, 48-port 10GB top-of-rack switch from the Arista 7100 Series. All 48 SFP/SFP+ ports run at 1GB or 10GB, so 1GB and 10GB hosts can share one switch.

Arista rates the 7148SX at 960 Gbps of switching capacity and 720 Mpps, with 1200 ns latency and 16K Layer 2 forwarding entries. EOS runs on a dual-core x86 CPU with 2 GB of DRAM and 2 GB of flash. Typical power draw is 600W. Management uses two 10/100/1000 ports, an RS-232 console on RJ45, and USB.

It has front-to-back airflow (port-side intake): the ports face the cold aisle and the fans exhaust toward the hot aisle. Five hot-swappable fans run N+1 and two hot-swappable 760W power supplies run 1+1 redundant. The chassis measures 17.4 x 1.75 x 20.25 in and weighs 29 lb. BGP, OSPF, ISIS, PIM and NAT need the Arista Enhanced L3 license (LIC-FIX-2-E), sold separately.

This listing is the switch itself in new open box condition. 4-post rails are quoted separately.

For racks that need the ports on the hot aisle, choose the DCS-7148SX-R back-to-front version. A DCS-7148SX-F seller refurbished unit is listed separately. For a spare power supply, the PWR-760AC power supply fits the 7100 Series.

This Arista DCS-7148SX-F switch is new open box and covered by the NetworkTigers one-year warranty.


Specifications

  • Network Ports : 48x 1/10GB SFP+
  • Management Ports : 2x 10/100/1000 mgmt, 1x RS-232 console, 1x USB
  • SFP Modules : None included
  • CPU : Dual-Core x86
  • VLAN ID's : 4094
  • AirFlow Direction : front-to-back (port-side intake)
  • Fan Module Options : FAN-7100-F
  • Power Supplies Included : 2x PWR-760AC (2 power supply bays)
  • Power Supply Options : PWR-760AC (760W AC)
  • PoE Budget : None
  • Switching Capacity : 960 Gbps
  • Forwarding Rate : 720 Mpps
  • MAC Address Table Size : 16,000
  • Latency : 1200 ns
  • DRAM and Flash : 2 GB DRAM, 2 GB flash
  • Model Number : DCS-7148SX-F
  • Part Number : DCS-7148SX-F
  • Condition : New


Included

  • One (1) NEW Arista DCS-7148SX-F 7100 Series 48x 10GB SFP+ Front-to-Back Airflow Switch as described above
