The Ruckus Brocade ICX7650-48ZP switch features 48 MultiGB PoE+ RJ45 ports, making it ideal for high-speed connectivity in enterprise networks. With four QSFP+ uplink ports and one expansion slot, this switch offers flexibility for future growth and scalability.
The advanced design of the ICX7650-48ZP ensures reliable performance under heavy network traffic loads. This switch is suitable for a variety of applications, from data centers to remote offices.
Overall, the Ruckus Brocade ICX7650-48ZP is a versatile and efficient networking solution that provides businesses with robust capabilities to meet their growing demands. Its combination of multiple connection options and power over Ethernet support makes it an excellent choice for modern networking requirements at scale.
Ruckus ICX7650-48ZP: 48-port switch: 24-port 100MbE/1GbE/2.5GbE/5GbE/10GbE POH and 24-port 1GbE. PoE+, 4xQSFP (either 2x100G or 4x40G active), modular slot, no PSU, no fans, no port module.
- Network Ports : 24x 100MbE/1GE/2.5GE/5GE/10 Gigabit Ethernet PoE+/PoH/UPoE RJ45, 24x 1 Gigabit Ethernet PoE+ RJ45
- Uplink Ports : 4x 40 Gigabit Ethernet QSFP+ (either 2x100G or 4x40G active)
- Management Ports : 1x Out of Band Management RJ45, 1x Serial Console RJ45, 1x USB Type C, 1x USB Type A
- Stacking Ports : Can stack on 4x 40G or 2x 100G rear facing QSFP ports - Aggregated stacking bandwidth (data rate, full duplex) = 2.4 Tbps
- Stacking Cable Options : Various Ruckus 40G/100G QSFP cables
- Module Slots : 1x Expansion Module Slot - Modules not included
- Module Options : ICX7650-1X100GQ (1-port 100GbE QSFP28), ICX7650-2X40GQ (2-port 40GbE QSFP+), ICX7650-4X10GF (4-port 1/10GbE SFP+)
- AirFlow Direction : Depends on Fan and PSU configuration
- Fan Module Options : 2x Fan Module Slots - None Included - Options are ICX-FAN12-E, ICX-FAN12-I
- Power Supplies Included : 2x PSU Slots - None Included
- Power Supply Options : RPS16-E, RPS16-I
- PoE Budget : 750W with one RPS16 power supply and 1,500W with two.
- Switching Capacity : 1.128 Tbps
- Forwarding Rate : 839 Mpps
- MAC Address Table Size : 80,000
- DRAM and Flash : 4GB DRAM
- Model Number : ICX7650-48ZP
- Part Number : ICX7650-48ZP
- Condition : New
- One (1) NEW Ruckus ICX7650-48ZP 24x MultiGB PoH 24x 1GB PoE+ RJ45 4x QSFP+ Switch as described above
