This listing is a new open box Cisco ISR4351-V/K9, the UC bundle of the 2RU ISR 4351 in Cisco's ISR 4000 Series. It has three onboard Gigabit Ethernet WAN/LAN ports, each able to take RJ45 copper or an SFP optic.
For expansion it offers three NIM slots, two SM-X service module slots (or one double-wide module) and one ISC slot. Cisco rates it at 200 Mbps aggregate throughput by default and 400 Mbps with the FL-4350-PERF-K9 performance license, which is sold separately. Memory is 4 GB of DRAM (16 GB maximum) and 4 GB of flash (16 GB maximum) by default. The default supply is the 450 W PWR-4450-AC; Cisco also lists the 1000 W PWR-4450-POE-AC for PoE and the PWR-4450-DC.
The -V part number is Cisco's UC bundle: the chassis plus a PVDM4-64 voice DSP module and the UC (Unified Communications) license. The PVDM4-64 handles up to 64 low-complexity (G.711) voice channels, 48 medium-complexity or 32 high-complexity, for conferencing and transcoding; T1/E1 voice on a T1/E1 NIM needs a PVDM4 installed on that NIM.
This new open box listing includes the router itself; SFP modules and network modules are not included. A seller refurbished unit is listed as the ISR4351-V/K9 refurbished UC bundle. In 1RU with four onboard ports, the ISR4431-V/K9 new UC bundle carries the same PVDM4-64 and UC license. This Cisco ISR4351-V/K9 router is new open box and covered by the NetworkTigers one-year warranty.
- Network Ports : 3x 1 Gigabit Combo (1 Gigabit Ethernet RJ45 or 1GB SFP)
- Management Ports : 1x RJ45 Serial Console, 1x Gigabit RJ45 Management, 1x Mini-USB Type B Console, 1x AUX ports, 1x USB 2.0
- Module Slots and Options : 3x NIM slots, 2x SM-X slots (or 1x double-wide), 1x ISC slot - network modules not included
- PVDM4 : 1x PVDM4-64 Included
- DRAM : 4 GB (installed) / 16 GB (max)
- Flash : 4 GB (installed) / 16 GB (max)
- Power Supplies : 1x PWR-4450-AC - options PWR-4450-POE-AC (1000 W AC with PoE), PWR-4450-DC
- System Throughput : 200Mbps-400Mbps
- Rack Mounts : Included (2-RU)
- Model Number : ISR4351-V/K9
- Part Number : ISR4351-V/K9, ISR4351-V/K9=, ISR4351-V/K9-WS
- Condition : New
- One (1) NEW Cisco ISR4351-V/K9 Integrated Services 4351 Voice Router w/ PVDM4-64 as described above
- SFP Modules Not Included
- Network Modules Not Included
