The HPE Aruba JW825A IAP-335 (US) Instant is a powerful wireless access point that supports the latest 802.11ac standard with dual radio functionality. It offers impressive connectivity options, operating on both the 2.4 GHz and 5 GHz frequencies.
With its advanced MU-MIMO technology and a high maximum data rate of up to 1733 Mbps, this WAP delivers exceptional performance for demanding environments. Its four-stream capability ensures efficient multi-user support while minimizing latency issues.
Ideal for medium to large-scale deployments in diverse industries such as education or hospitality sectors, it provides seamless integration into existing infrastructure thanks to its flexible deployment options including wall-mounting or ceiling tile bracket mounting scenarios.
Aruba JW825A: Aruba Instant IAP-335 (US) 802.11n/ac Dual 4x4:4 MU-MIMO Radio Integrated Antenna 2.5+1 GbE AP.
- Wi-Fi Standard : Wi-Fi 5 (802.11n/ac)
- Managed By : Aruba Instant Mode - pre-configured for controllerless Instant operation
- Suggested Use : The 330 Series Access Points deliver a best-in-class, next-generation 802.11ac Wi-Fi infrastructure that is ideal for lecture halls, auditoriums, public venues, and high-density office environments.
- Region : FCC (USA) B
- Radios : 1x 5 GHz Client Access - 802.11ac Wave 2, 4x4 MU-MIMO with 4 spatial streams, 1x 2.4 GHz Client Access - 802.11n 4x4 MIMO, up to 600 Mbps max rate with 4SS/HT40 clients
- Spatial Streams per Radio : 4
- Maximum Data Rate : 1733 Mbps
- Bluetooth / IoT Radios : Bluetooth Low Energy (BLE) - Integrated BLE radio enabling location-based services, asset tracking, indoor wayfinding, and proximity-based push notification capabilities via Aruba Meridian.
- PoE Standard : Power over Ethernet (PoE) - 48 Vdc (nominal) 802.3af/802.3at compliant source - Injector sold separately.
- DC Power Input : Direct DC source - 48Vdc nominal, +/- 5%. Adapter sold separately.
- Uplink Ports : 1x 1 Gigabit Ethernet PoE RJ45 Auto-sensing link speed (100/1000/2500/5000BASE-T) and MDI/MDX - 2.5Gbps and 5Gbps speeds comply with NBase-T and 802.3bz specifications
- Other Ports : 1x RJ45 Console, 1x USB 2.0 (Type A), One 10/100/1000BASE-T Ethernet network interface (RJ45)
- Antenna Type : Internal Antenna - 4x (vertically polarized) integrated 2.4 GHz downtilt omni-directional antennas for 4x4 MIMO with peak antenna gain of 3.8dBi per antenna.
- Antenna Ports : None - Internal Antenna
- MIMO Technology : 4-stream multi-user MIMO (MU-MIMO) and 4 spatial streams (4SS)
- Mounting Options : JX961A - Suspended ceiling rail mount kit, JW046A / JW047A - Flat-surface wall mount kit, JW048A / JW049A - Flat-surface wall mount kit, secure box, JY706A - Indoor flat-surface mount kit - None Included
- Mounts Included : The AP ships with two (black) mounting clips to attach to a 9/16-inch or 15/16-inch flat T-bar drop-tile ceiling (JW045A)
- Model Number : JW825A
- Part Number : JW825A, IAP-335, IAP-335-US, APIN0335
- Condition : New
- One (1) NEW HPE Aruba IAP-335 JW825A US Instant Wi-Fi 5 802.11ac Internal Antenna WAP as described above
- Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website - Power Adapter Not Included
- Power Injector Not Included
- Mount Bracket Not Included
