The Cisco Meraki MR28-HW is an entry-level Wi-Fi 6 (802.11ax) indoor access point managed from the Meraki cloud dashboard. It is built for small offices, retail shops, home offices, waiting rooms and other light- to medium-density spaces that want Wi-Fi 6 and Meraki cloud management at the lowest cost in the lineup.
It runs 2x2:2 on both 2.4 GHz and 5 GHz, for up to 1.5 Gbps combined radio rate, and adds a Bluetooth Low Energy radio for beacons and BLE scanning. Security includes a Layer 7 firewall, WIDS/WIPS, WPA3, and 802.1X. It has one Gigabit Ethernet port (RJ45) and runs on standard 802.3af PoE, so it works with your existing PoE switch or the MA-PWR-30W-XX AC adapter.
Choose the MR28 when you need reliable Wi-Fi 6 for a small site and do not need a dedicated scanning radio or a multigigabit uplink. It ships with its mount plate and is sold unclaimed, so you can claim it into your own Meraki organization. A Meraki licence is required and is sold separately. Covered by our 365-day warranty.
Cisco Meraki MR28-HW: Wi-Fi 6 802.11ax, 2x2:2 dual-band, up to 1.5 Gbps, BLE, 1x Gigabit RJ45, 802.3af PoE, mount plate included, unclaimed.
- Wi-Fi Standard : Wi-Fi 6 (802.11ax)
- Managed By : Meraki Dashboard
- Licensing : This unit is Unclaimed - Licences can be purchased directly from Meraki
- Suggested Use : Designed for basic, medium-density deployments, the MR28 provides enterprise-grade security and simple management.
- Region : US
- Radios : Dual Radio - 5 GHz, 2.4 GHz
- 2 spatial streams per radio - it's a 2x2 : 2 design on both the 2.4 GHz and 5 GHz radios.
- Maximum Data Rate : Radios offer a combined dual-radio aggregate frame rate of 1.5 Gbps*, with up to 1,201 Mbps in the 5 GHz band and 286 Mbps in the 2.4 GHz band
- Bluetooth / IoT Radios : The MR28 has an integrated Bluetooth Low Energy (BLE 5) radio with two functions. Beacon - for location services/wayfinding. And BLE scanning - for visibility of Bluetooth devices in the environment
- PoE Standard : Power over Ethernet - 37 - 57 V (802.3af compatible) - Power over Ethernet injector sold separately (MA-INJ-4, MA-INJ-6)
- DC Power Input : 1x DC power connector (5.5 mm x 2.5 mm, center positive) - DC Power Adapter sold separately
- Uplink Ports : 1x 1 Gigabit Ethernet RJ-45
- Antenna Type : Internal Omni-Directional Antenna (5.4 dBi gain at 2.4 GHz, 6 dBi gain at 5 GHz)
- Antenna Ports : None - Internal
- MU-MIMO Technology : With support for features of 802.11ax, the MR28 offers MU-MIMO and UL/DL OFDMA
- Mounting Options : Mounting Kit Included. MA-MNT-CLG-1 can be purchased separately for mounting MR28 to drop-ceiling grids
- Mounts Included : 1x Mount plate, 1x Mount Kit (Wall screws are included)
- Model Number : MR28-HW
- Part Number : MR28-HW
- Condition : New
- One (1) NEW Cisco Meraki MR28-HW Cloud Managed Wi-Fi 6 802.11ax Int Ant Unclaimed WAP Used as described above
