Dell N1124P-ON N1100 Series 24x 1GB PoE+ RJ45 4x 10GB SFP+ EMC Switch

Dell N1124P-ON N1100 Series 24x 1GB PoE+ RJ45 4x 10GB SFP+ EMC Switch

Ask for quote
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: Seller refurbished
Pre-owned, tested by qualified techs, working, reset-to-factory default, grade A condition, and parts needed for normal functions are included (as described in the listing).
Warranty: 365 days
Warranty coverage period
SKU: NSH-9914
UPC: 884116349556


The Dell N1124P-ON N1100 Series Switch is a reliable and efficient business networking solution. With 24 PoE+ RJ45 ports, it provides power over Ethernet to connected devices, eliminating the need for separate power supplies. The switch also features four 10GB SFP+ uplink ports, allowing for high-speed data transfer.

With a PoE budget of 190W, this EMC switch can easily handle various powered devices such as IP phones or network cameras. Its switching capacity of 128Gbps ensures smooth handling of large amounts of data traffic while maintaining low latency levels.

This Dell switch has a MAC address table size of 16,000 entries and supports a forwarding rate 96 Mpps (million packets per second). These specifications make it suitable for small to medium-sized networks that require fast and secure communication between multiple devices.

Dell N1124P-ON: 24x 10/100/1000Mbps half/full duplex ports, 4x SFP/SFP+ 1/10GbE ports, 12xPoE/PoE+ ports 190W PoE power budget, 1 RU switch form factor.


  • Network Ports : 24x 1 Gigabit Ethernet RJ45 (12x PoE+)
  • Uplink Ports : 4x 10 Gigabit Ethernet SFP+
  • Management Ports : 1x USB
  • Firmware Version : Dell EMC Networking OS 6
  • Power Supplies Included : 1x Internal AC Power Supply
  • PoE Budget : 190W
  • Switching Capacity : 128Gbps
  • Forwarding Rate : 96Mpps
  • MAC Address Table Size : 16,000
  • Rack Mounts : Included (1-RU)
  • Model Number : N1124P-ON
  • Part Number : N1124P-ON
  • Condition : Seller refurbished


  • One (1) Seller Refurbished Dell N1124P-ON N1100 Series 24x 1GB PoE+ RJ45 4x 10GB SFP+ EMC Switch as described above
  • One (1) Power Cord Included
  • One (1) Set of Rack Mount Brackets Included

Not Included

  • Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
    Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website
  • Transceiver Modules Not Included
