Dell N1548 N1500 Series 48x 1GB RJ-45 4x 10GB SFP+ EMC Switch

Dell N1548 N1500 Series 48x 1GB RJ-45 4x 10GB SFP+ EMC Switch

$ 606.99
Only 2 remaining
In stock means that we have the product available to meet your delivery commitment. If it is on the web site, it is available for sale and we can ship it that day.
  Call if you need more
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: Seller refurbished
Pre-owned, tested by qualified techs, working, reset-to-factory default, grade A condition, and parts needed for normal functions are included (as described in the listing).
Warranty: 365 days
Warranty coverage period
SKU: NSH-5977
UPC: 884116268994

Overview

The Dell N1548 N1500 Series Switch is an EMC-certified switch that offers reliable and efficient network connectivity. Its 48x 1GB RJ-45 ports enable seamless data transmission over Ethernet connections. The four built-in 10GB SFP+ interfaces allow for high-speed fiber optic connectivity.

Featuring a switching capacity of up to 176 Gbps, this switch ensures smooth traffic flow within your network environment. It also boasts a forwarding rate of approximately 164Mpps (million packets per second), ensuring quick data delivery without delays or bottlenecks.

With a MAC address table size of 16,000 entries, the N1548 provides ample space for efficiently mapping devices on your network.

Dell N1548: 48x RJ45 10/100/1000Mb auto-sensing ports, 4x SFP+ ports, 1 integrated 100W PSU.


Specifications

  • Network Ports : 48x 1 Gigabit Ethernet RJ-45
  • Uplink Ports : 4x 10 Gigabit Ethernet SFP+
  • Management Ports : 1x RJ-45 Serial Console, 1x USB Type A
  • Static routes : 256 (IPv4)/128 (IPv6)
  • Dynamic routes : 256 (IPv4)
  • Firmware Version : Dell EMC Networking OS 6
  • SFP Modules : None Included
  • Power Supplies Included : 1x 100W AC Internal Included. Optional 720W External Power Supply - RPS720 (sold separately).
  • Flash Memory : 256MB
  • Switching Capacity : 176 Gbps
  • Forwarding Rate : 164Mpps
  • MAC Address Table Size : 16,000
  • VLANs Supported : 512
  • Rack Mounts : Included (1-RU)
  • Model Number : N1548
  • Part Number : N1548, 0V143P, V143P, 463-7711
  • Condition : Seller refurbished


Included

  • One (1) Seller Refurbished Dell N1548 N1500 Series 48x 1GB RJ-45 4x 10GB SFP+ EMC Switch as described above
  • One (1) Power Cord Included
  • One (1) Set of Rack Mount Brackets Included

Not Included

  • Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
    Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website
  • Transceiver Modules Not Included
