The Juniper AP43E-US is an advanced Wi-Fi 6 access point that provides high-speed wireless connectivity. With a 4x4:4 spatial stream configuration and external antennas, this device offers enhanced coverage and improved network performance.
This access point supports the latest IEEE 802.11ax standard (Wi-Fi 6), enabling faster data transfer speeds up to four times that of previous-generation devices. It also simultaneously delivers increased capacity for multiple connected devices, making it suitable for busy environments such as offices or public spaces.
Equipped with powerful hardware capabilities and intelligent management features, the Juniper AP43E-US ensures seamless roaming between different access points without any interruptions in connection quality.
- Wi-Fi Standard : 802.11ax (Wi-Fi 6), including OFDMA, 1024-QAM, MU-MIMO, TWT, and BSS Coloring, backwards compatible with 802.11a/b/g/n/ac
- Managed By : Cloud platform only, AI-driven
- Licensing : UNCLAIMED, license-free. No active subscription is included
- Suggested Use : Indoor deployment leveraging integrated IoT sensors and a dedicated IoT interface port for environmental context and location-based services, external antennas suit environments needing customized coverage patterns or harsher conditions
- Region : US
- Radios : 3x total, one 2.4GHz, one 5GHz, plus a dedicated dual-band third radio for WIDS/WIPS, spectrum analysis, and location analytics
- Spatial Streams per Radio : 4x streams on both 2.4GHz and 5GHz using 4x4 by 4, for 8x access streams total plus the scan radio
- Maximum Data Rate : 1148 Mbps on 2.4GHz and 2400 Mbps on 5GHz, up to 3.5 Gbps dual-band combined
- Bluetooth / IoT Radios : Bluetooth 5.0, with a 16-element directional virtual antenna array plus an omnidirectional Bluetooth antenna
- PoE Standard : 802.3at or 802.3bt, PoE output on the second port requires 802.3bt input on the primary port
- DC Power Input : Supported via optional 12V/3A DC power supply, adapter takes 100-240VAC input, sold separately,
- Uplink Ports : 1x 100/1000Base-T, 2.5GBase-T RJ45, PoE input, plus 1x 10/100/1000Base-T RJ45 with optional PoE output
- Other Ports : 1x USB 2.0 support interface, 1x IoT port (analog/digital I/O)
- Antenna Type : External, connectorized, no antennas included by default
- Antenna Ports : 6x RP-SMA male connectors, 4x dual-band for client radios, 2x dual-band for the third radio, all located on the rear panel alongside the other ports
- Antenna Options : External antennas sold separately, selection depends on coverage pattern and gain requirements for the deployment
- Mounting Options : Universal bracket (included), plus optional threaded rod or T-rail adapters for specific ceiling/wall types, sold separately
- Mounts Included : Universal bracket included in the box with the AP (APBR-U)
- Model Number : AP43E-US
- Part Number : AP43E-US
- Condition : New
- One (1) NEW Juniper AP43E-US Wi-Fi 6 802.11ax US External Antenna Unclaimed Indoor WAP as described above
