NEW Juniper AP43-US Wi-Fi 6 802.11ax US Internal Antenna Unclaimed Indoor WAP
New

NEW Juniper AP43-US Wi-Fi 6 802.11ax US Internal Antenna Unclaimed Indoor WAP

Ask for quote
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-1122
UPC: 8517650060237

Overview

The Juniper AP43-US is an advanced wireless access point (AP) that supports the latest Wi-Fi 6 (802.11ax) standard to deliver high-performance connectivity in demanding environments. With its internal antenna configuration, this AP utilizes cutting-edge 4x4:4SS technology for enhanced coverage and increased capacity.

Featuring next-generation security protocols and multiple radios working concurrently, the Juniper AP43-US ensures seamless performance even in crowded networks. It offers robust network management capabilities with cloud-based activation and centralized control through Contrail SD-LAN or Mist Cloud platforms.

Designed for scalability, this sleek access point can effortlessly adapt to changing business requirements while providing a consistent user experience across devices. Its intelligent radio resource allocation optimizes spectrum utilization efficiently, minimizing interference from neighboring APs.


Specifications

  • Wi-Fi Standard : 802.11ax (Wi-Fi 6), including OFDMA, 1024-QAM, MU-MIMO, TWT, and BSS Coloring, backwards compatible with 802.11a/b/g/n/ac
  • Managed By : Cloud platform only, AI-driven
  • Unclaimed : Yes - this unit ships unclaimed
  • Suggested Use : Indoor deployment leveraging integrated IoT sensors and a dedicated IoT interface port for environmental context and location-based services
  • Region : US
  • Radios : 3x total, one 2.4GHz, one 5GHz, plus a dedicated dual-band third radio for WIDS/WIPS, spectrum analysis, and location analytics
  • Spatial Streams per Radio : 4x streams on both 2.4GHz and 5GHz using 4x4 by 4, for 8x access streams total plus the scan radio
  • Maximum Data Rate : 1148 Mbps on 2.4GHz and 2400 Mbps on 5GHz, up to 3.5 Gbps dual-band combined
  • Bluetooth / IoT Radios : Bluetooth 5.0, with a 16-element directional virtual antenna array plus an omnidirectional Bluetooth antenna
  • PoE Standard : 802.3at or 802.3bt, PoE output on the second port requires 802.3bt input on the primary port - injector sold separately
  • DC Power Input : Supported via optional 12V/3A DC power supply, adapter takes 100-240VAC input, sold separately
  • Uplink Ports : 1x 100/1000Base-T, 2.5GBase-T RJ45, PoE input, plus 1x 10/100/1000Base-T RJ45 with optional PoE output
  • Other Ports : 1x USB 2.0 support interface, 1x IoT port (analog/digital I/O), 1x 12VDC input jack for optional power supply
  • Antenna Type : Internal omnidirectional, 4x on 2.4GHz (4dBi peak gain), 4x on 5GHz (6dBi peak gain), plus the 16-element directional Bluetooth array
  • Mounting Options : Threaded rod mounts (3/8 in or 16mm), or various T-rail adapters (9/16 in, 15/16 in, or 1.5 in), all sold separately
  • Mounts Included : Universal Bracket Included (APBR-U)
  • Model Number : AP43-US
  • Part Number : AP43-US
  • Condition : New


Included

  • One (1) NEW Juniper AP43-US Wi-Fi 6 802.11ax US Internal Antenna Unclaimed Indoor WAP as described above
