The HPE Aruba R0X26A is the CX 6405 switch bundle: a 7U modular chassis with five open line card slots, built around the 6400 management module and fan trays. It shares line cards, power supplies and management modules with the larger ten-slot 6410.
As HPE ships it, the bundle contains the R0X24A chassis, one R0X31A management module and two R0X32A fan trays, along with a 2-post rack mount kit and cable management kit. Power supplies are not included by HPE. The chassis has four power supply bays for the R0X35A or R0X36A, and a second management module slot. Airflow is port-side intake (front-to-back) only. HPE lists the bundle at 12.1 x 17.5 x 17.7 in and 64.7 lb, and a 4-post rack kit, R0X37A, is sold separately.
This listing ships one new chassis bundle, as HPE ships it, with no power supplies and no line cards.
Power supplies are ordered separately: the new R0X35A 1800W power supply is listed, and the R0X36A power supply supplies 3000W at high line. For a seller refurbished R0X26A chassis that includes one power supply, see its own listing. This HPE Aruba R0X26A switch chassis is new and covered by the NetworkTigers one-year warranty. The original packaging may have been opened to inspect the contents.
- Network Ports : Dependent on the line cards installed - see Module Options
- Management Ports : 1x RJ45 console port, 1x USB-C console port, 1x OOBM port, 1x USB Type-A host port (R0X31A management module)
- Module Slots : 5x line card slots, 2x management module slots - 1x R0X31A management module included
- Module Options : R0X38B, R0X39B, R0X40B, R0X41A, R0X42A, R0X43A, R0X44A, R0X45A, R0X44C, R0X45C
- AirFlow Direction : Front-to-back (port-side intake) only - no back-to-front version
- Fan Module Options : 2x R0X32A fan trays included (2 fan tray bays)
- Power Supplies Included : None included (4 power supply bays)
- Power Supply Options : R0X35A, R0X36A
- Switching Capacity : 14 Tbps
- Forwarding Rate : 5.7 Bpps
- MAC Address Table Size : 32,768
- Model Number : R0X26A
- Part Number : R0X26A
- Condition : New
- One (1) NEW HPE Aruba R0X26A CX 6405 Switch Chassis Bundle as described above
