The HPE Aruba R4H13A AP-574 (US) by Hewlett Packard Enterprise is a connectorized outdoor wireless access point with dual-radio 802.11ax support. It provides 4x4 MIMO on 5 GHz and 2x2 MIMO on 2.4 GHz, with maximum 5 GHz data rates from 8.6 Mbps to 4803 Mbps (MCS0 to MCS11, HE20 to HE160).
Regulatory model APEX0574, US domain. The unit uses external antennas via six N-type female connectors and supports Wi‑Fi 6 features across both bands. It is designed for outdoor deployment and integrates with Aruba wireless management platforms. Mounting hardware and antenna selection are dependent on site requirements.
HPE Aruba R4H13A: HPE Aruba Networking AP-574 (US) 802.11ax 2x2:2/4x4:4 Dual Radio 6xNf Connectorized Outdoor AP.
- Wi-Fi Standard : 802.11ax (Wi-Fi 6)
- Managed By : Aruba Central, Mobility Controller, or Instant (standalone)
- Regulatory model numbers : APEX0574
- Suggested Use : Outdoor Deployment
- Region : US
- Radios : Dual radio, 5 GHz 4x4 MIMO and 2.4 GHz 2x2 MIMO
- Spatial Streams per Radio : 4 (5 GHz), 2 (2.4 GHz)
- Maximum Data Rate : Up to 4.8 Gbps (5 GHz HE160, max), 574 Mbps (2.4 GHz HE40, max)
- Bluetooth / IoT Radios : Bluetooth 5 and 802.15.4 (Zigbee), integrated omnidirectional antenna, peak gain 4.2 dBi
- PoE Standard : PoE 802.3at/bt (Class 4 or higher)
- DC Power Input : US
- Uplink Ports : 2x Ethernet Ports (1x HPE SmartRate PoE-PD RJ-45, 1x 1 Gigabit Ethernet PoE-PD RJ-45)
- Other Ports : USB-C console interface, 1x Reset Button
- Antenna Ports : 4x Nf connectors (5 GHz), 2x Nf connectors (2.4 GHz) — 6 total - Antennas not included
- Antenna Options : JW023A (5dBi Omni Pair), JW024A (14dBi 30x30 Dir), JW025A (14dBi 70 Sector), JW034A (5dBi 90x90 Dual-Band), JW035A (8dBi 60x60 Dual-Band) - None Included
- Mounting Options : AP-OUT-MNT-V1A (Pole/Wall Long), AP-270-MNT-V2 (Pole/Wall Short), AP-270-MNT-H1 (Hanging/Tilt), AP-270-MNT-H2 (Flush Wall/Ceiling), AP-270-MNT-H3 (Hanging/Dual-Tilt)
- Mounts Included : None Included
- Model Number : R4H13A
- Part Number : R4H13A, AP-574, AP-574-US, APEX0574
- Condition : Seller refurbished
- One (1) Seller refurbished HPE Aruba AP-574 R4H13A (US) Wi-Fi 6 802.11ax External Antenna Outdoor WAP as described above
- Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website - Mount Bracket Not Included
- Power Injector Not Included
- Antennas Not Included
