The HPE Aruba R4H13A AP-574 (US) by Hewlett Packard Enterprise is a connectorized outdoor wireless access point with dual-radio 802.11ax support. It provides 4x4 MIMO on 5 GHz and 2x2 MIMO on 2.4 GHz, with maximum 5 GHz data rates from 8.6 Mbps to 4803 Mbps (MCS0 to MCS11, HE20 to HE160).
Regulatory model APEX0574, US domain. The unit uses external antennas via six N-type female connectors and supports Wi‑Fi 6 features across both bands. It is designed for outdoor deployment and integrates with Aruba wireless management platforms. Mounting hardware and antenna selection are dependent on site requirements.
HPE Aruba R4H13A: HPE Aruba Networking AP-574 (US) 802.11ax 2x2:2/4x4:4 Dual Radio 6xNf Connectorized Outdoor AP.
- Wi-Fi Standard : 802.11ax (Wi-Fi 6)
- Managed By : Aruba Central, Mobility Controller, or Instant (standalone)
- Regulatory model numbers : APEX0574
- Suggested Use : Outdoor Deployment
- Region : US
- Radios : Dual radio, 5 GHz 4x4 MIMO and 2.4 GHz 2x2 MIMO
- Spatial Streams per Radio : 4 (5 GHz), 2 (2.4 GHz)
- Maximum Data Rate : Up to 4.8 Gbps (5 GHz HE160, max), 574 Mbps (2.4 GHz HE40, max)
- Bluetooth / IoT Radios : Bluetooth 5 and 802.15.4 (Zigbee), integrated omnidirectional antenna, peak gain 4.2 dBi
- PoE Standard : PoE 802.3at/bt (Class 4 or higher)
- DC Power Input : US
- Uplink Ports : 2x Ethernet Ports (1x HPE SmartRate PoE-PD RJ-45, 1x 1 Gigabit Ethernet PoE-PD RJ-45)
- Other Ports : USB-C console interface, 1x Reset Button
- Antenna Ports : 4x Nf connectors (5 GHz), 2x Nf connectors (2.4 GHz) — 6 total - Antennas not included
- Antenna Options : JW023A (5dBi Omni Pair), JW024A (14dBi 30x30 Dir), JW025A (14dBi 70 Sector), JW034A (5dBi 90x90 Dual-Band), JW035A (8dBi 60x60 Dual-Band) - None Included
- Mounting Options : AP-OUT-MNT-V1A (Pole/Wall Long), AP-270-MNT-V2 (Pole/Wall Short), AP-270-MNT-H1 (Hanging/Tilt), AP-270-MNT-H2 (Flush Wall/Ceiling), AP-270-MNT-H3 (Hanging/Dual-Tilt)
- Mounts Included : None Included
- Model Number : R4H13A
- Part Number : R4H13A, AP-574, AP-574-US, APEX0574
- Condition : New
- One (1) NEW HPE Aruba AP-574 R4H13A (US) Wi-Fi 6 802.11ax External Antenna Outdoor WAP as described above
