The HPE Aruba R4W44A AP-565 (US) Outdoor Wireless Access Point, manufactured by Hewlett Packard Enterprise, features a ruggedized form factor and supports dual 2x2:2 MIMO radios. It operates on both 5 GHz and 2.4 GHz frequencies with Wi-Fi 6 capability (802.11ax), delivering up to 1.2 Gbps transmission speed.
Designed for outdoor deployment in the US regulatory domain, the AP-565 supports Power over Ethernet (PoE) input via its single Gigabit Ethernet port compatible with IEEE 802.3af/at standards. The unit includes pole or wall mounting options for flexible placement and is built to withstand environmental exposures typical of exterior installations such as campuses or public venues requiring expanded wireless coverage zones across dual bands for various client devices using modern WLAN protocols.
HPE Aruba Networking AP-565 (US) 802.11ax Dual 2x2:2 Radio Integrated Omni Antenna Outdoor AP.
- Wi-Fi Standard : Wi-Fi 6 (802.11ax)
- Managed By : Unified AP, meaning it supports all three management modes - Aruba Central (the primary recommended management method), Controller-Managed Mode, Aruba Instant Mode
- Suggested Use : Outdoor Deployment - Weatherproof and temperature hardened
- Region : US
- Radios : 1x 5 GHz Client Access - 802.11ax (Wi-Fi 6), 2x2 MU-MIMO with 2 spatial streams, 1x 2.4 GHz Client Access - 802.11ax (Wi-Fi 6), 2x2 MU-MIMO with 2 spatial streams, 1x Integrated 802.15.4/Zigbee radio
- Spatial Streams per Radio : 2
- Maximum Data Rate : 1.2 Gbps
- Bluetooth / IoT Radios : 1x Bluetooth 5 - Integrated Bluetooth 5 radio supporting IoT deployments, location-based services, and asset tracking
- PoE Standard : Power over Ethernet (PoE+) 802.3at-compliant - Power sources sold separately
- DC Power Input : N/A
- Uplink Ports : 1x 1 Gigabit Ethernet PoE+ RJ-45
- Antenna Type : Built-in Omni Directional Antennas
- Regulatory model numbers : APEX0565
- Mounting Options : Optional mounting kits - AP-OUT-MNT-V1A, AP-270-MNT-V2, AP-270-MNT-H1, AP-270-MNT-H2
- Mounts Included : None included
- Model Number : R4W44A
- Part Number : R4W44A, AP-565, AP-565-US, AP-565 US, APEX0565
- Condition : Seller refurbished
- One (1) Seller Refurbished HPE Aruba AP-565 R4W44A US Wi-Fi 6 802.11ax Internal Antenna Outdoor WAP as described above
- Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website - Power Injector Not Included
- Wall Mount Bracket Not Included
