Cisco's WS-C3850-48T-L is the 48-port non-PoE Catalyst 3850, 1RU with 48 10/100/1000 RJ45 ports for data-only access. The part number ends in -L, which Cisco names the LAN Base feature set, Layer 2 switching with limited static routing.
It runs on a PWR-C1-350WAC in the first of two power supply bays; the second bay takes another PWR-C1 AC supply or the PWR-C1-440WDC. Its network module slot takes the C3850-NM-4-1G, the C3850-NM-2-10G, or the C3850-NM-4-10G for four 10GB SFP+ uplinks. Cisco rates it at 176 Gbps of switching capacity and 130.95 Mpps forwarding. Rear StackWise-480 ports stack it at 480 Gbps, and StackPower connectors let stacked switches share power supplies.
As a new open box unit it comes with Cisco's default PWR-C1-350WAC power supply, three fan modules and 19-inch rack mount brackets. No network module or transceivers are included.
Other feature sets of this switch are the NEW WS-C3850-48T-S IP Base switch and the NEW WS-C3850-48T-E IP Services switch. Pair it with a NEW C3850-NM-4-10G module for four 10GB SFP+ ports. If you need to power phones or access points, the NEW WS-C3850-48P-L 48-port PoE+ switch adds PoE+. A seller refurbished WS-C3850-48T-L is listed separately.
This Catalyst 3850 switch is new open box and covered by the NetworkTigers one-year warranty.
- Network Ports : 48x 1 Gigabit Ethernet RJ45
- Uplink Ports : Through the use Expansion Module - See "Module Slots and Options"
- Management Ports : 1x USB Type A, 1x Console Mini USB Type B, 1x RS-232 RJ45 Management, 1x Gigabit Ethernet Management
- Stacking Ports : 2x Cisco StackWise 480 connectors, 2x Cisco StackPower Connectors | Stacking bandwidth is 480 Gbps
- Stacking Cable Options : CAB-SPWR-30CM, CAB-SPWR-150CM (StackPower), STACK-T1-50CM, STACK-T1-1M, STACK-T1-3M (StackWise) - Cables sold separately
- Module Slots : 1x Expansion Module Slots - Modules are not included
- Module Options : C3850-NM-4-1G (4x 1GB SFP), C3850-NM-2-10G (4x 1GB SFP/ 2x 10GB SFP+), C3850-NM-4-10G (4x 10GB SFP+)
- Switch Version : LAN Base
- Fan Module Options : 3x FAN-T1 (3 fan bays)
- Power Supplies Included : 1x PWR-C1-350WAC (2 power supply bays)
- Power Supply Options : PWR-C1-350WAC, PWR-C1-715WAC, PWR-C1-1100WAC, PWR-C1-440WDC
- Switching Capacity : 176 Gbps
- Forwarding Rate : 130.95 Mpps
- MAC Address Table Size : 32,000
- Model Number : WS-C3850-48T-L
- Part Number : 3850-48T-L, WS-C3850-48T-L, WS-C3850-48T-L-WS
- Condition : New
- One (1) NEW Cisco WS-C3850-48T-L Catalyst 3850 48x 1GB RJ45 1x Module Slot Switch as described above
