This seller refurbished Cisco Catalyst C9300L-48PF-4G-A (Network Advantage version) is a 48-port Gigabit PoE+ access switch with an 1100W default supply and four fixed 1G uplinks, built for dense closets of phones, access points, and cameras.
- Four 1G SFP uplinks, fixed: The four uplinks run at 1G on SFP ports, so there is no module slot. The C9300L-48PF-4X has four 10G/1G SFP+ uplinks instead.
- Stack cable lengths: Stacks use the optional kit, which has two adapters and a 0.5m cable, with 1m and 3m cables also offered.
- On-board RAM and flash: The switch has 8 GB of memory and 16 GB of flash, with a USB 3.0 slot that takes an SSD of up to 240 GB.
- 890W from the default supply: The default 1100W supply provides 890W of PoE, and a 350W second supply lifts that to 1,240W.
Compare: Don't need 890W? The C9300L-48P-4G-A provides 505W from a 715W default supply. Want 10G uplinks? The C9300L-48PF-4X-A has four 10G/1G SFP+ uplinks.
What ships with this unit is listed under What's Included. See all Cisco Catalyst 9300 switches and parts.
Every unit is tested before it ships and is covered by our 365-day warranty. Need several, or a matched set with power supplies and fans? Ask us for a quote.
- Network Ports : 48x Gigabit Ethernet Full PoE+ RJ45
- Uplink Ports : 4x 1 Gigabit Ethernet SFP
- Management Ports : 2x USB, 1x Mini USB
- Stack Technology : StackWise-320
- Stacking Options : C9300L-STACK-KIT - Ordered Separately
- Stacking Cable Options : STACK-T3-50CM, STACK-T3-1M, STACK-T3-3M - None Included
- Supported Stack Members : Other C9300L SKUs with same license level (Number of Members - 8)
- Switch Version : Network Advantage
- Fan Module Options : 3x FAN-T2 Modules Included
- Power Supplies Included : 1x PWR-C1-1100WAC-P Included - 2x Slots - 2nd Power Supply ordered separately.
- Power Supply Options : PWR-C1-1100WAC-P, PWR-C1-350WAC-P, PWR-C1-715WAC-P - Not Included
- PoE Budget : 890W
- Switching Capacity : 104 Gbps (Switching Capacity with Stacking - 424 Gbps)
- Forwarding Rate : 77.38 Mpps (Forwarding Rate with Stacking - 315.48 Mpps)
- MAC Address Table Size : 32,000
- Model Number : C9300L-48PF-4G-A
- Part Number : C9300L-48PF-4G-A, C9300L-48PF-4G-A=, C9300L-48PF-4G-A-WS
- Condition : Seller refurbished
- One (1) Seller Refurbished Cisco C9300L-48PF-4G-A 48x 1GB Full PoE+ RJ45 4x 1GB SFP Net Advantage Switch as described above
- One (1) Power Cord Included
- One (1) AC Power Supply Included
- Three (3) Fan Modules Included
- One (1) Set of Rack Mount Brackets Included
- Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website - Transceiver Modules Not Included
