NEW HPE Aruba J9727A 2920-24G-PoE+ 20x 1GB PoE+ RJ45 4x Combo 2x ModSlot Switch

Ask for quote
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-4741
UPC: 886112322144

Overview

The HPE Aruba J9727A is the 2920-24G-PoE+ Switch: 20 PoE+ Gigabit RJ45 ports and 4 dual-personality ports (RJ45 or SFP, also PoE+), fed by a 575 W J9738A supply for a 370 W PoE budget. Switching capacity is 128 Gbps at 95.2 Mpps.

Uplinks come from two optional 10GbE modules, the J9731A SFP+ or the J9732A 10GBASE-T. A separate slot takes the J9733A stacking module for stacks of up to four switches.

The 48-port version is the 2920-48G-PoE+. Where a 48-port closet needs more than 370 W of PoE, the 740 W model carries a 1050 W supply. A seller refurbished 2920-24G-PoE+ is also listed.

This HPE Aruba J9727A switch is new open box and covered by the NetworkTigers one-year warranty.


Specifications

  • Network Ports : 20x 1 Gigabit Ethernet PoE+ RJ45
  • Uplink Ports : 4x 1 Gigabit Ethernet Combo (SFP/RJ45)
  • Management Ports : 1x Dual-Personality (RJ45 or USB micro-B), 1 USB 1.1, 1x RJ45 Out of Band Management
  • Stacking Ports : 1x Stacking Module Slot - J9733A Stacking Module not included
  • Stacking Options : J9733A is only option for stacking module
  • Stacking Cable Options : J9734A (0.5m), J9735A (1m) - Cables not included
  • Module Slots : 2x Expansion Slots - Modules not included
  • Module Options : J9731A (HPE 2x 10GB SFP+), J9732A (2x 10GB RJ45) None included. Sold separately.
  • Power Supplies Included : 1x J9738A (HP X332 575W 100-240VAC to 54VDC Modular Power Supply Included - 1x PSU Slot - 1x PSU Required.
  • PoE Budget : 370W
  • Switching Capacity : 128 Gbps
  • Forwarding Rate : 95.2 Mpps
  • MAC Address Table Size : 16,000
  • Alternative Model Number : 2920-24G-PoE+
  • Capacity : IPv4 routing table entries 2048 IPv6 routing table entries 256
  • Model Number : J9727A
  • Part Number : J9727A, 2920-24G-PoE+
  • Condition : New


Included

  • One (1) NEW HPE Aruba J9727A 2920-24G-PoE+ 20x 1GB PoE+ RJ45 4x Combo 2x ModSlot Switch as described above
