Cisco Meraki PWR-C1-1100WAC-P-M Catalyst 9300-M 1100W AC P-Rated Power Supply

The Cisco Meraki PWR-C1-1100WAC-P-M is the 1100W AC hot-swap power supply for Catalyst 9300-M switches managed from the Meraki Dashboard. It is the default supply in the C9300-24U-M, C9300-24UX-M, C9300-48U-M, C9300-48UXM-M, and C9300-48UN-M, and the upgrade option for the C9300-24P-M and C9300-48P-M, which ship with a 715W supply.

As the primary supply it gives an 822W PoE budget on the C9300-48U-M and C9300-48P-M, 830W on the C9300-24U-M, and 560W on the C9300-24UX-M. Input is 115 to 240 VAC at 50 to 60 Hz; it does not run on 100V circuits.

Each Catalyst 9300-M has two supply slots. A second supply adds PoE capacity and redundancy, and a failed unit can be swapped without powering the switch down. StackPower can also share capacity across a stack. Cisco lists the non-M PWR-C1-1100WAC-P as compatible with this part. Fit the two supplies to separate circuits or UPS units where possible, so one breaker cannot take the switch down.

The supply fits the C9300-48U-M 48-port UPoE switch and is the upgrade for the C9300-48P-M 48-port PoE+ switch. For Meraki MS390 switches, see the MA-PWR-1100WAC, a separate part number.

This seller refurbished Cisco Meraki PWR-C1-1100WAC-P-M power supply is tested, working, and covered by the NetworkTigers one-year warranty.
