NEW Dell S3048-ON 48x 1GB RJ45 4x 10GB SFP+ Front-to-Back Air 210-AEDM Switch
New

NEW Dell S3048-ON 48x 1GB RJ45 4x 10GB SFP+ Front-to-Back Air 210-AEDM Switch

$ 349.99
$ 312.99
Only 2 remaining
In stock means that we have the product available to meet your delivery commitment. If it is on the web site, it is available for sale and we can ship it that day.
  Call if you need more
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-1926 ASK FOR QUOTE
UPC: 011110490254

Overview

The Dell S3048-ON is a 1RU access switch with 48x 1GB RJ45 ports and 4x 10GB SFP+ ports. It suits campus closets and server-room management networks where many copper devices connect at gigabit speed and a few fiber links run upstream.

Dell rates it at 260 Gbps of switching capacity and 131 Mpps, with a 4 MB packet buffer and a MAC table of up to 80K entries. Each of the four SFP+ ports can serve as an uplink or a stacking port, and up to six units can be stacked. The chassis has two power supply bays and three hot-swappable fan modules, matched to the airflow direction. This is the standard-airflow version: air moves from the I/O panel to the power supplies (front-to-back, port-side intake), so the ports face the cold aisle.

This listing is new open box. Transceivers are not included.

If your rack needs the opposite airflow, the S3048-ON-RA listing is the back-to-front version. The same model is also available seller refurbished. This Dell S3048-ON switch is new open box and covered by the NetworkTigers one-year warranty.


Specifications

  • Network Ports : 48x 1 Gigabit Ethernet RJ45
  • Uplink Ports : 4x 10 Gigabit Ethernet SFP+
  • Management Ports : 1x RJ45 Console/Management port with RS232 signaling
  • Stacking Ports : 2x Stacking ports - cables sold separately
  • Stacking Cable Options : WYDVP - 0.25m, GG661 - 1m, N7T3J - 3m
  • Switch Version : OS9
  • Fan Module Options : 3x Fan Modules - Front-to-Back Airflow (I/O Panel to PSU Airflow - Normal Airflow)
  • Power Supplies Included : 1x PSU Included - 2x Total Slots - Front-to-Back Airflow (I/O Panel to PSU Airflow - Normal Airflow)
  • Switching Capacity : 260Gbps (full-duplex), 130 Gbps (half-duplex)
  • Forwarding Rate : 131 Mpps
  • MAC Address Table Size : 80,000
  • Alternative Dell Part Numbers : XF0X9, 210-AHCE
  • Model Number : S3048-ON
  • Part Number : S3048-ON, XF0X9, 210-AHCE
  • Condition : New


Included

  • One (1) NEW Dell S3048-ON 48x 1GB RJ45 4x 10GB SFP+ Front-to-Back Air 210-AEDM Switch as described above
