The Cisco Meraki MR42 is an indoor Wi-Fi 5 (802.11ac Wave 2) access point managed from the Meraki Dashboard. It has a 2.4 GHz and a 5 GHz client radio, each 3x3 MU-MIMO with 3 spatial streams, for an aggregate frame rate of 1.9 Gbps, with up to 1,300 Mbps on 5 GHz and 600 Mbps on 2.4 GHz.
A third dual-band radio is dedicated to WIDS/WIPS, spectrum analysis, and location analytics, and a fourth radio provides Bluetooth Low Energy beacons. Integrated omnidirectional antennas give 5 dBi of gain on 2.4 GHz and 5.5 dBi on 5 GHz.
The uplink is one Gigabit RJ-45 port. Full function needs 802.3at PoE+, at 20W maximum; 802.3af runs the AP in a restricted mode. A 12V DC input is also available with an adapter sold separately. The unit measures 10.0 x 6.1 x 1.5 inches and weighs 25 oz, and the MA-MNT-MR-8 mount kit is included. It fits offices, schools, and hospitals with medium to high client density.
If you need your own antennas, the MR42E-HW is the external-antenna version. For 4x4 radios, see the MR52-HW, and for Wi-Fi 6, the MR44-HW. A spare MA-MNT-MR-8 mount kit is also available. The access point is sold unclaimed; a Meraki license is required, purchased separately.
This seller refurbished Cisco Meraki MR42-HW access point is tested, working, and covered by the NetworkTigers one-year warranty.
- Wi-Fi Standard : Wi-Fi 5 (802.11ac Wave 2)
- Managed By : Cisco Meraki Dashboard (cloud)
- Licensing : Unclaimed - Meraki license required, sold separately
- Suggested Use : Indoor - offices, schools, hospitals (medium to high density)
- Region : US (FCC)
- Radios : 2.4 GHz and 5 GHz client radios plus dual-band WIDS/WIPS scanning radio and BLE radio
- Spatial Streams per Radio : 3x3 MU-MIMO with 3 spatial streams on each band
- Maximum Data Rate : 1.9 Gbps aggregate (1,300 Mbps 5 GHz, 600 Mbps 2.4 GHz)
- Bluetooth / IoT Radios : BLE radio - beacon support
- PoE Standard : 802.3at PoE+ (20W max) - 802.3af restricted mode
- DC Power Input : 12V DC input (5.5 x 2.5 mm, center positive) - adapter sold separately
- Uplink Ports : 1x 10/100/1000 RJ-45
- Antenna Type : Internal omnidirectional - 5 dBi (2.4 GHz), 5.5 dBi (5 GHz)
- Antenna Ports : None (internal antennas)
- Mounting Options : Desk, wall, or ceiling - MA-MNT-MR-8
- Mounts Included : Yes - MA-MNT-MR-8 kit
- Model Number : MR42-HW
- Part Number : MR42-HW, MR42-HW=, MR42-HW-WS
- Condition : Seller refurbished
- One (1) Seller Refurbished Cisco Meraki MR42-HW Wi-Fi 5 802.11ac Internal Ant Unclaimed WAP w/ Mounts as described above
- One (1) MA-MNT-MR-8 Mount Kit Included
- Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website - Power Injector Not Included - sold separately or use PoE switch
- Power Adapter Not Included- sold separately or use PoE switch
- Licences are sold directly by Meraki
- Ceiling Mount Kit Not Included
