The Cisco Meraki MX67-HW is a desktop security and SD-WAN appliance managed from the Meraki Dashboard. It has five Gigabit RJ45 ports: one dedicated WAN port, three dedicated LAN ports, and one port that can be set as LAN or as a second WAN uplink. None of the ports supply PoE.
Meraki rates it at 700 Mbps stateful firewall throughput, 400 Mbps maximum VPN throughput, and 400 Mbps with next-generation firewall detection enabled. It is sized for a small branch with up to 50 devices.
Power comes from an external adapter, and the appliance draws 5W idle and 14W at full load. It measures 9.4 x 5.1 x 1.1 inches and weighs 1.74 lb, and it sits on a desk or mounts on a wall. The appliance is sold unclaimed; a Meraki license is required, purchased separately.
The replacement adapter is the MA-PWR-30WAC 30W power adapter. For built-in Wi-Fi, see the MX67W-HW, and for a built-in LTE modem, the MX67C-HW. If the site needs more LAN ports and PoE+, the MX68-HW has twelve Gigabit ports.
This Meraki security appliance is new open box and covered by the NetworkTigers one-year warranty.
- Network Ports : 4x 1 Gigabit Ethernet RJ45 LAN (1x convertible to WAN)
- Uplink Ports : 1x 1 Gigabit Ethernet RJ45 WAN, 1x convertible LAN or WAN port
- Management Ports : 1x USB
- AC Power Included : External 30W adapter - MA-PWR-30WAC
- Stateful Throughput : 700 Mbps (400 Mbps advanced security)
- VPN Throughput : 400 Mbps
- Licenses and SSL VPN : Unclaimed - Meraki MX license required, sold separately
- Rack Mount Hardware : Desktop or wall mount
- Model Number : MX67-HW
- Part Number : MX67-HW, MX67-HW=, MX67-HW-WS
- Condition : New
- One (1) NEW Cisco Meraki MX67-HW 700 Mbps 5x 1GB RJ45 Unclaimed Firewall as described above
