NEW Cisco Meraki MS120-24P-HW 24x 1GB PoE+ RJ-45 4x 1GB SFP Unclaimed Switch
New

NEW Cisco Meraki MS120-24P-HW 24x 1GB PoE+ RJ-45 4x 1GB SFP Unclaimed Switch

$ 735.99
$ 674.99
Only 2 remaining
In stock means that we have the product available to meet your delivery commitment. If it is on the web site, it is available for sale and we can ship it that day.
  Call if you need more
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-3386
UPC: 810979012993

Overview

The Cisco Meraki MS120-24P-HW is a 24-port PoE+ switch with 4 SFP interfaces designed for small to medium-sized networks. This unclaimed switch has a switching capacity of 56 Gbps and a forwarding rate of 41.67mpps, making it ideal for high-speed data transmission.

With support for up to 16,000 MAC addresses in its table size, the MS120-24P-HW offers efficient network management capabilities without sacrificing performance. The module options allow flexibility in configuration based on specific networking needs while ensuring reliable connectivity across all devices. The compact form factor and easy installation make this switch suitable for various deployment scenarios that require Power over Ethernet functionality combined with gigabit speeds over both RJ-45 and fiber connections.

Cisco Meraki MS120-24P-HW: MS120 Series 24x Gigabit Ethernet RJ-45 PoE+ and 4x 1G SFP Switch with an internal AC power supply and 370 W PoE Budget.


Specifications

  • Network Ports : 24x 1 Gigabit Ethernet PoE+ RJ-45 with auto negotiation and crossover detection (auto-MDIX crossover)
  • Uplink Ports : 4x 1 Gigabit Ethernet SFP
  • Management Ports : 1x RJ-45 Management port
  • Stacking : Virtual Stacking enables switch port configuration changes on the dashboard interface without the need to physically stack switches
  • License : License is not included. This is sold directly by Meraki.
  • Switch Version : Automatic firmware upgrades with scheduling control
  • Fan Module Options : Fanless Design
  • Power Supplies Included : 1x Internal AC Power Supply - 100 - 240 VAC, 47-63 Hz
  • PoE Budget : 370W (Up to 15 ports simultaneously at 30W per port 802.3at PoE+)
  • Switching Capacity : 56 Gbps
  • Forwarding Rate : 41.67mpps
  • MAC Address Table Size : 16,000
  • Model Number : MS120-24P-HW
  • Part Number : MS120-24P-HW, MS120-24P-HW=, MS120-24P-HW-WS
  • Condition : New


Included

  • One (1) NEW Cisco Meraki NEW Cisco Meraki MS120-24P-HW 24x 1GB PoE+ RJ-45 4x 1GB SFP Unclaimed Switch as described above
